Pump EVOPLUS D 120/280.50 M
Pump EVOPLUS D 120/280.50 M
⬤ Out of stock
Shipping options
Store stock information
Sorry, not available at the moment
pump EVOPLUS D 120/280.50 M
General specs
- Garums:280
- Grupa:siltumapgāde
- Nominālais izmērs (DN):50
- Savienojuma veids:atloks
- Spriegums:230v
- Sērija:evoplus d
Specs
- Product code: 60151012
- Barcode: 8059893011893
- Brand: DAB
0 Reviews
Rating 0You must be logged in to leave a review
Product description
Wet rotor electronic circulator designed for the circulation of water in conditioning and heating systems in commercial building service.
The integrated variable frequency drive ensures greater comfort and protection against water hammer action, and also saves energy by adapting the motor speed to actual requirements. The display enables easy configuration and the setting of the six operating modes (proportional differential pressure, constant differential pressure, constant curve adjustment, constant and proportional differential pressure in relation to water temperature, economy function).
The circulator is supplied with flanged suction and delivery ports (also in the twin version). The single version includes insulation shells. The Evoplus D versions are supplied as standard with an automatic non- return suction valve incorporated in the delivery port to avoid water recirculating through the unit when it is not running and a blank flange for servicing either of the two motors. Possibility of remote control with the DConnect service (DConnect Box supplied separately).
Flow rate (range): From 3 m3/h to 30,12 m³/h
Head: Up to 11,91 m
Type of pumped liquid: Clean, free from solid substances and mineral oils, not viscous
Glycol percentage (maximum): 30%
Liquid temperature (range): -10°C / +110°C
Operation pressure (maximum): 16 bar / 1600 kPa
Flanging or threading: Flange DN 32, 40, 50, 65 with PN 6, 10, 16 and Flange DN 80, 100 with PN 6
Motor protection class: IP X4
Motor insulation class: F
Energy efficiency index: EEI ≤ 0,23
Impeller material: Technopolymer
Single phase power input: 230 V 50 Hz
Type of installation: Fixed with horizontal motor axis
