FKC 80 40.4 T5 400DOL
FKC 80 40.4 T5 400DOL
⬤ Out of stock
Shipping options
Store stock information
Sorry, not available at the moment
FKC 80 40.4 T5 400DOL
General specs
- Grupa:kanalizācija
- Sērija:fkc
Specs
- Product code: 60176872
- Barcode: 8059893117243
- Brand: DAB
0 Reviews
Rating 0You must be logged in to leave a review
Product description
Design for the pumping of wastewater and sewage from buildings and sites in private, commercial, industrial areas in accordance with European Standard EN 12050-1.
Vortex impeller with maximum solids handling with new no-clogging shape, single channel impeller with high efficency and compliance with European Standard EN 12050-1. Single-unit cartridge seal with double mechanical seals, SiC-SiC at the pump side, SiC-C at the motor side. All seals are independent of rotation direction.
Premium Efficiency IE3, three-phase, squirrel-cage motor. Seal monitoring by a moisture sensor in the seal chamber, which signals an inspection alert if there is leakage at the mechanical seals (optional).
Bi-metallic switch in stator windings, with max temperature (130°C).
Stainless steel shaft.
Designed with high resistance fatigue fracture.
Impeller type: Single vane impeller
Solid handling:
Nominal power : 4 kW
Outlet: DN 80
Perfomance range: from 14,4 m³/h to 137 with 17,4 m head.
Fluid: wastewater and sewage from buildings and sites in private, commercial, industrial areas.
Fluid PH: 6.5 ÷ 12
Fluid temperature range: from 0° to +40°C. for higher temperature please contact our sale offices.
Max installation Depth: 20 m (with a proper cable length)
Type of installation: fixed by Coupling Unit, portable in vertical position with pedestal.
Continuous working with total submerged applications, or discontinuous S3 with respect of minimum levels.
Approvals: EN 12050-1 e Ex (ATEX , IECEx)
Degree of protection: IP 68
Insulation class: F
Max starting /hours: 20
