Evoplus Sanitary Circulator

Evoplus Sanitary Circulator

DAB
896.01 €
Product code:60151158

Out of stock

Shipping options

Pickup at shop
Will be specified
Free shipping
Delivery
Will be specified
20.00€
Venipak locker
Will be specified
2.99€

Store stock information

Sorry, not available at the moment

Twitter Facebook
app.product-showproduct-thumb
Evoplus Sanitary Circulator
896.01 €

General specs

  • Garums:250
  • Grupa:siltumapgāde
  • Nominālais izmērs (DN):40
  • Spriegums:230v
  • Sērija:evoplus b

Specs

  • Product code: 60151158
  • Barcode: 8059893025333
  • Brand: DAB

0 Reviews

Rating 0
5
0
4
0
3
0
2
0
1
0

You must be logged in to leave a review

Product description

   Wet rotor electronic circulator with bronze pump body designed for the circulation of domestic hot water in small collective domestic, residential, civil and commercial systems.
   It is equipped with an integrated variable frequency drive to ensure better all-round performance and energy efficiency, and also to protect the system against water hammer action. The operating parameters,         like proportional or constant differential pressure and constant speed, can be easily viewed and set on the user-friendly display.
   Synchronous motor with permanent magnet rotor. Flanged inlet and outlet ports.
   WRAS and ACS certification. Possibility of remote control with the DConnect service, the DConnect Box is supplied separately.

   Flow rate (range): From 2 m3/h to 11,85 m³/h
   Head: Up to 11,14 m
   Type of pumped liquid: Clean, free from solid substances and mineral oils, not viscous, chemically neutral
   Liquid temperature (range): From -10°C to +110°C
   Operation pressure (maximum): 16 bar / 1600 kPa
   Flanging or threading: Thread 1" 1/2 or Flanging DN 32, DN 40, PN 6, PN 10, PN 16
   Motor protection class: IP 44
   Motor insulation class: F
   Impeller material: Technopolymer
   Single phase power input: 230 V 50 Hz
   Type of installation: Fixed with horizontal motor axis
   Certification: WRAS, ACS
