EVOPLUS 110/180 SAN M
EVOPLUS 110/180 SAN M
⬤ Out of stock
Shipping options
Store stock information
Sorry, not available at the moment
EVOPLUS 110/180 SAN M
General specs
- Garums:180
- Grupa:siltumapgāde
- Nominālais izmērs (DN):2,5
- Spriegums:230v
- Sērija:evoplus san
Specs
- Product code: 60151147
- Barcode: 8059893014344
- Brand: DAB
0 Reviews
Rating 0You must be logged in to leave a review
Product description
Wet rotor electronic circulator with bronze pump body designed for the circulation of domestic hot water in small collective domestic, residential, civil and commercial systems.
It is equipped with an integrated variable frequency drive to ensure better all-round performance and energy efficiency, and also to protect the system against water hammer action. The operating parameters, like proportional or constant differential pressure and constant speed, can be easily viewed and set on the user-friendly display.
Synchronous motor with permanent magnet rotor. Flanged inlet and outlet ports.
WRAS and ACS certification. Possibility of remote control with the DConnect service, the DConnect Box is supplied separately.
Flow rate (range): From 2 m3/h to 8,3 m³/h
Head: Up to 11,07 m
Type of pumped liquid: Clean, free from solid substances and mineral oils, not viscous, chemically neutral
Liquid temperature (range): From -10°C to +110°C
Operation pressure (maximum): 16 bar / 1600 kPa
Flanging or threading: Thread 1" 1/2 or Flanging DN 32, DN 40, PN 6, PN 10, PN 16
Motor protection class: IP 44
Motor insulation class: F
Impeller material: Technopolymer
Single phase power input: 230 V 50 Hz
Type of installation: Fixed with horizontal motor axis
Certification: WRAS, ACS
