FEKA FXV 25.22 TNA
FEKA FXV 25.22 TNA
⬤ Out of stock
Shipping options
Store stock information
Sorry, not available at the moment
FEKA FXV 25.22 TNA
General specs
- Grupa:kanalizācija
- Pludiņslēdzis:iebūvēts
- Sērija:feka
Specs
- Product code: 60191267
- Barcode: 8059893223005
- Brand: DAB
0 Reviews
Rating 0You must be logged in to leave a review
Product description
Submersible pump for sewage in commercial building service. Certification according to EN 12050-1 waste water regulation. Suitable for fixed installations with coupling device or mobile resting directly on the bottom of the tank. High performance super vortex impeller with full solid handle. Double mechanical seal in silicon carbide completely protected in an oil chamber and not in contact with the pumped liquid. Motor shaft in stainless steel AISI 431 for P2 <1,2 kW and AISI 304 for P2> 1,5 kW, resin cable gland with quick coupling. The reduced dimensions and the delivery ports both flanged and threaded make it ideal for replacements. Designed for fast maintenance thanks to a construction solution that provides easy access to the main components of the pump. Single-phase versions with integrated capacitor, available with float for automatic operation (MA) with powers up to 1,5 kW. In the three-phase versions, protection is the responsibility of the user. ATEX version available for use in potentially explosive environments (ATES certifications: II2G Ex db k IIB T4 or IEC EX: Ex db IIB T4 Gb).
Flow rate maximum: 59,7 m3/h
Head up to: 18,5 m
Immersion dept (maximum): 20 m
Type of pumped liquid: Waters with filamentary bodies, paper or textile material in the presence of domestic or civil waste
Free passage: 65 mm
Supported liquid temperature (maximum and minimum):
+50°C (+60°C for a short period of time)
+40°C ATEX version
Outlet connection: From 2", DN 50, DN 65
Impeller type: Vortex
Start time (maximum) per hour: 20/h
Class of protection: IP 68
Motor insulation class: F
Single phase power input: 1x 220-240V 50Hz
Three phase power input: 3x 400V 50Hz / 3x 230V 50Hz only on request
Maximum dry run time: 10 min
Power cable (m) and plug: 10 m
Possible type of installation: mobile when on the ground, fixed with coupling
Certification: EN 12050-1 \ ATEX
Special versions on request: Different cable lengths, different voltages and frequencies
